96 x 48 mm.

PNP/NPN

-10 °C to 50 °C

90-260 VAC

IP65

- Housing: Dimension 96 x 48 mm
- Supply voltage: 10 ... 30 V DC, 90 ... 260 V AC
- Display: 6-digit 7-segment red LED; 14 mm (0...999999)
- Input 3 Input A , B , Reset (Contact, VDC, Sensor NPN, PNP, Encoder)
- Reset : reset button infront or use a leg reset
- Input frequency 60 kHz (Especial the mode Pulse Counter)
- Scale factor 0.0001-99.9999
- Ambient temperature: ?20 ... +65 ?C
- Data retention: via EEPROM 1 Million of memory cycles or 10 years
- Protection: IP 65
- Count like model Multifunction in one
- 2 x Total counter : count 2 the group works at the same time
- Total counter + Timer : count and count the time at the same time
- Total counter + Tachometer : count and speed temple at the same time
- 2 x Timer : count 2 group times work at the same time
