Suitable for harsh applications (58 mm).

-20°C up to +85 °C

stainless steel

RS422 5 VDC, RS422 10 - 30 VDC or Push - pull 10 - 30 VDC, Push - pull 5 - 30 VDC (choose to order)

Hollow shaft 6, 8,10,12 mm.

Push-pull Transistor and Line-driver (D)

10, 20, 25, 30, 50, 60, 100, 120, 125, 127, 150,180, 200, 216, 240, 250, 254, 256, 300, 314, 360,375, 400, 500, 512, 600, 625, 720, 745, 750, 762,800, 900, 927, 1000, 1024, 1250, 1270, 1400,1500, 1800, 2000, 2048, 2250, 2400, 2500, 3000,3600, 4000, 4096, 5000

Line out and M23 ,M12 (choose to order)

IP 66

European quality standards from Germany
