shaft 58-63.5 mm./hollow shaft 63-65 mm.

-40 °C ... +80 °C

zinc die-cast

10-30 Vdc

shaft 6 mm,10 mm,1/4",3/8" hollow shaft 10 mm,12 mm,14 mm,15 mm,3/8",1/2"

CANopen/CANopenLift

16/12/25/28 bit

Connector M12

IP67

Germany

It works with CANopen or CANopenLift bus system and is designed with optical technology that provides excellent performance.
Which is suitable for work that requires very high communication speed, such as mobile application work, robot/mechanical arm work, and elevator system work.
It also provides a high measurement resolution of up to 28 bits, and has an additional RS422 incremental output with a resolution of 2048.
