-10 °C to 55 °C

IP 54

- Electrical connection: Tin-plated tabs Ø 1.6 mm [0.063"] with push-on connectors (counter)
- Tin plated tabs 0.8 x 2.8 mm [0.032 x 0.11"] (socket box)
- Rated voltages: Counting mechanism:12/24/48/115 V DC ±10 % , 24/48/115/230 V AC ± 10 %
- Figures: Counter 4.5 mm [0.177"] , Preset 4 mm [0.158"]
- Colour of housing: Black
- Colour of figures: Counter: white on black
- Preset: yellow on black
- Shaft: stainless steel
- Mounting position: optional
- Service life: approx. 100 x 106 Pulse
- Weight: approx. 130 g [4.586 oz]
- Test voltage: 2 000 V, effective
- Switching contact: 1 change over contact (micro switch),release in 2nd half-step on the preset number
