output, withstand current 10 (6) A

24 V AC/DC

-

IP 40

-

Wall installation

- Presence detector (PIR)
- Square detection area
- Installation type : Wall installation
- Light switch output (relay, 230 V) / Presence switch output (relay, potential-free)
- Automatic control of lighting and HVAC
- The switching behaviour of the presence detector is controlled by presence and light
- The parameters are set via the potentiometer
- Operating voltage 24 V AC/DC
- Recommended installation height 2 – 3.5 m
- Setting range brightness 50 – 1600 lx
- Light switch-off delay 2 min-15 min
- Presence switch-off delay 1-60 min
- Ambient temperature +0 °C … +50 °C
- Type of protection IP 40
