Brand : Carlo Gavazzi
|
Model : EM271 |
Type : Energy Meter Analyzer Properties
Conectivity
RS485 Depend on ordered
screen size
72x72 mm, DIN 45x72 mm
installation
Panel mount
body size
72x72 mm
Accuracy
±0.5% RDG
operating temperature range
-20°C to +55°C
Weight
400g
power supply
- MV5: 230VLN/400VLL AC
- MV6: 120VLN/230VLL AC
- MV6: 120VLN/230VLL AC
output
- OS: dual static output (opto-mosfet) and serial port
- 2S: dual RS485 serial communication port
- 2S: dual RS485 serial communication port
Measuring range
- electric energy meter "Economical price" suitable for load center cabinets
- Electrical system can measure both 1-phase and 3-phase
- Electrical system can measure both 1-phase and 3-phase
measure current
Maximum 400 A with CT with 4 current ranges: 60 A, 100 A,200 A, 400 A
pressure gauge
400 VAC , 660 VAC
temperature/humidity
-
IP
IP50
details
-
Data Sheet
