45 x 54 x 60 mm. used to attach to 35 mm rails.

-20°C to 50°C, IP 20

1 relay output 10 A 250 VAC

230 – 240 V AC

IP 20

- Output contactor relay
- daily program
- With backup power (NiHM rechargeable battery)
- can be programmed by rocker Switch lever up to 96 steps
- Use the time base from the quartz seal
- Switch to the shortest 15 minutes
- DuoFix Spring Terminal
- There is a manual switch in 3 positions: ON-AUTO-OFF
- Working 24 hours.
- High accuracy Easy to use by operating from the rocker.
- Command ON/OFF immediately by rocking the switch 96 levers
- 3-day backup power system will be fully functional when connected for at least 3 days of use
- There is a screen display in 12 / 24 hours.
- Timer can be set every 15 minutes
