45 x 54 x 60 mm. used to attach to 35 mm rails.

-20°C to 50°C, IP 20

1 relay output 16 A 250 VAC

230 – 240 V AC

IP 20

- Drive : Quartz-controlled stepper motor
- Program : Daily program
- Backup battery can last : 3 days
- Minimum program : 15 min
- Program every : 15 minutes
- Time error of 25 °C : ≤ ± 1 s/day (quartz)
- Switching output : Potential-free and phase-independent
- Switch: 96 positions
